Automatic self priming China factory JET water pump

We look forward to cooperating with you and welcome you to visit RICH factory to purchase our latest hot-selling automatic booster system pumps—high-quality products offered at competitive prices.
Composed of a peripheral pump, JET pump, or centrifugal pump, the automatic booster system pump integrates a water pump, pressure tank, airtight pressure switch, pressure gauge, and connecting flexible pipe. This integration enables full automation, making the system much more convenient to use. Pre-charged with an air pressure of approximately 0.12 MPa before leaving the factory, the pressure tank is equipped with a non-toxic rubber membrane.
These systems deliver suitable mains water pressure to meet the demands of modern domestic and industrial applications, ensuring sufficient water supply for all user outlets. Notably, most pumps in our product range—including self priming water pumps, electric centrifugal pumps, electric jet pumps, and QB60 pumps—can be utilized to form automatic booster systems.

●APPLICATIONS
This product is designed exclusively for cleanwater or non-aggressive liquids, with no sand or other solid impurities allowed.It is well-suited for small domestic water supply, automatic sprinkler systems, small air conditioning systems, and a range of supporting equipment.

●DESIGN FEATURES
-Pump body: cast iron
-Impeller: Brass
-Bearing: C&U/NSK
-100% copper winding
-Built-in thermal protector for single phase motor
-Motor shaft: AlSI 304 welded shaft
-Mechanical seal: Carbon/Ceramic/NBR/SUS304

●OPERATING LIMITS
-Total suction:9M
-Max. operating pressure: 8 bar.
-Max. ambient temperature: +40℃
-Max. liquid temperature: +90℃

●MOTOR
-Insultation class: B
-Protection: IP44
-Speed of rotation: 2850rpm
